Fujitsu Airstage J-II Series User Manual

LED105
CODE No.
Setting Mode
LED104
CODE No.
Setting Function
Factory
setting
Remarks
2 8
Change of unit
(Temperature)
0 0 Celsius (°C)
l
0 1 Fahrenheit (°F)
2 9
Change of unit
(Pressure)
0 0 MPa
l
0 1 psi
3 0
Outdoor unit
capacity save
setting
0 0 Level 1 (stop)
l
The capacity limit can be selected by the
external input terminal (CN133) when operating
with the “Outdoor unit capacity save function.”
The lower the level, the more the e󰀨ect
of energy saving, but the cooling/heating
performance will also drop.
0 1 Level 2
0 2 Level 3
0 3 Level 4
0 4 Level 5
3 1 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
3 4 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
3 5
Presence of
heater selection
control using
outdoor
temperature
0 0 Disable
l
Setting required to validate the setting of heater
selection control using outdoor temperature 1
and 2 (setting value: 03 or 04) in eld setting 61
(indoor unit) for heater control switching.
For details, refer to Chapter 8. 1-2-2.
EXTERNAL OUTPUT.
0 1 Enable
3 6
Outdoor
temperature
zone boundary
temperature
A
0 0 -4.0°F (-20°C)
l
Setting required if changing of the outdoor
temperature setting for heat pump prohibition
zone is required when heater selection
control using outdoor temperature 1 and 2 are
performed on the indoor unit.
For details, refer to Chapter 8. 1-2-2.
EXTERNAL OUTPUT.
0 1 -0.4°F (-18°C)
0 2 3.2°F (-16°C)
0 3 6.8°F (-14°C)
0 4 10.4°F (-12°C)
0 5 14.0°F (-10°C)
0 6 17.6°F (-8°C)
0 7 21.2°F (-6°C)
0 8 24.8°F (-4°C)
*1: Do not set this for outdoor units with Slave setting.
- (07 - 76) -
