LED105
CODE No.
Setting Mode
LED104
CODE No.
Setting Function
Factory
setting
Remarks
2 0
Switching
between
batch stop or
emergency stop
0 0 Batch stop
l
This mode selects the pattern of the stop
function to be operated by the external input
terminal (CN134).
•Batch stop: The stop of all indoor units
connected to same refrigerant system due to
input signal coming from CN134.
•Emergency stop: When emergency stop is
actuated, the indoor unit does not accept the
operation command from the remote controller.
On the other hand, when the emergency
stop is released (no input from CN134), the
air conditioner does not return to the original
operation until operate indoor unit by the remote
controller.
0 1 Emergency stop
2 1
Operation
mode selecting
method
0 0
Priority given to the
rst command
l
Select the priority setting of the operation
mode.
•Priority given to the rst command: Priority is
given to the operation mode which is set rst.
•Priority given to external input of outdoor unit:
Priority is given to the operation mode which is
set by the external input terminal (CN132).
•Priority given to administrative indoor unit:
Priority is given to the operation mode of the
administrative indoor unit which is set by the
wired remote controller.
0 1
Priority given to
external input of
outdoor unit
0 2
Priority given to
administrative indoor
unit
2
2 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
2 3 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
0 2 Prohibited
0 3 Prohibited
2 4 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
0 2 Prohibited
0 3 Prohibited
2 5 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
0 2 Prohibited
0 3 Prohibited
2 6 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
2 7 Prohibited
0 0 Prohibited
l
Setting prohibited
0 1 Prohibited
- (07 - 75) -
