Fujitsu Airstage J-II Series User Manual


SWITCH TABLE
DIP-SW
type A
SET1
1 Prohibited (Indoor unit capacity setting)
2 Prohibited (Indoor unit capacity setting)
3 Prohibited (Indoor unit capacity setting)
4 Prohibited (Indoor unit capacity setting)
SET2
1 Prohibited (Indoor unit capacity setting)
2 External input select "edge/pulse"
3 Indoor unit fan setting for external heater
4 Prohibited
SET3
1 Wireless remote controller custom code switch 1
2 Wireless remote controller custom code switch 2
3 Prohibited
4 Prohibited
SET4
1 Drainage function switch (Slim Duct type only)
2
Auto louver grille setting switch (Mini Duct and Slim Duct type
only)
3 Prohibited
4 Prohibited
type B SW1 Remote controller wire type switch
Rotary
SW
type C
IU AD
x 1
Indoor unit address switch 1
IU AD
x 10
Indoor unit address switch 2
REF AD
x1
Refrigerant circuit address switch 1
REF AD
x10
Refrigerant circuit address switch 2
type D RC AD Remote controller address switch
- (07 - 83) -
FUNCTION SETTING FUNCTION SETTING

Fujitsu Airstage J-II Series Specifications

General

Brand	Fujitsu
Model	Airstage J-II Series
Category	Air Conditioner
Language	English
