DIP SWITCH SETTING
z
SET2 setting
●
External input select “Edge/Pulse”
(
u
...Factory setting)
SET2-2 External input select
u
OFF Edge
ON Pulse
●
Indoor unit fan setting for external heater
It is a function to delay the stop of cooling fan when the air conditioner is stopped.
When external heater is connected, turn "ON" this switch.
When you connect external heater, be careful enough.
(
u
...Factory setting)
SET2-3 Fan delay
u
OFF Disable
ON Enable
●
SET2-4 setting prohibited
(
u
...Factory setting)
SET2-4
u
OFF Fixed at OFF
ON Setting prohibited
- (07 - 84) -
