Fujitsu Airstage J-II Series User Manual

z
SW1 setting
●
Remote controller wire type setting switch
(
u
...Factory setting)
SW1 Remote controller wire type
u
2WIRE 2 Wire type
3WIRE 3 Wire type

ROTARY SWITCH SETTING
z
IU AD setting
●
Indoor unit address switch
Sets the indoor unit addresses.
Refer to "1-3. MANUAL ADDRESS SETTING METHOD" for indoor unit address conversion
table.
INDOOR UNIT ADDRESS SWITCH (Factory setting IU AD x 1: 0, IU AD x 10: 0)
Rotary SW Description Remarks
IU AD x 1 Indoor unit address Switch 1 Indoor unit address (the rst digit)
IU AD x 10 Indoor unit address Switch 2 Indoor unit address (the second digit)
z
REF AD setting
●
Refrigerant circuit address switch
Sets the refrigerant circuit address.
Refer to "1-3. MANUAL ADDRESS SETTING METHOD" for refrigerant circuit address
conversion table.
REFRIGERANT CIRCUIT ADDRESS SWITCH (Factory setting REF AD x 1: 0, REF AD x 10: 0)
Rotary SW Description Remarks
REF AD x 1 Refrigerant circuit address Switch 1 Refrigerant circuit address (the rst digit)
REF AD x 10 Refrigerant circuit address Switch 2 Refrigerant circuit address (the second digit)
- (07 - 87) -
FUNCTION SETTING FUNCTION SETTING
