Fujitsu Airstage J-II Series User Manual

z
Dimensions
Liquid
pipe
1-9/16 (40)
2-13/16 (72)
1-9/16 (40)
(5 (127))
(3-3/8 (85))
4-5/8 (117)
24-5/16 (617)
P2-3/8 (60) x 7 = 16-9/16 (420)
3/8 (10)
1-5/8 (42)
3/8 (10)
Dis-
charge
gas pipe
Suction
gas pipe
1-9/16 (40)
3-1/8 (80)
5 (127)
(6-1/16 (154))
7-3/4 (197)
29-13/16 (757)
3/8 (10)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
2-3/8
(60)
2-3/8
(60)
3-1/8
(80)
3-1/8
(80)
2-3/8
(60)
3-1/8
(80)
3-1/8
(80)
Unit: in. (mm)
1-9/16 (40)
2-3/4 (70)
(6 (152))
4-11/16 (112)
3/8 (10)
1-9/16 (40)
3/8 (10)
2-13/16 (72)
7-3/16 (182)
26-1/16 (662)
P2-3/8 (60) x 7 = 16-9/16 (420)
- (10 - 28) -
OPTIONAL PARTS OPTIONAL PARTS
