Fujitsu Airstage J-II Series User Manual


MODEL: UTP-J1806A
z
Port diameters
Liquid
pipe
ø1/4 (6.35)
ø3/8 (9.52)
ø1/4 (6.35)
ø3/8 (9.52)
ø1/2 (12.70)
ø1/2 (12.70)
ø1/2 (12.70)
ø5/8 (15.88)
Dis-
charge
gas
pipe
REDUCER
ø1/2 (12.70)
ø5/8 (15.88)
ø3/8 (9.52)
ø1/2 (12.70)
ø5/8 (15.88)
ø1/2 (12.70)
ø5/8 (15.88)
ø3/4 (19.05)
ø7/8 (22.22)
ø3/8 (9.52)
ø3/4 (19.05)
Suction
gas
pipe
REDUCER
EXPANDER
ø1/2 (12.70)
ø5/8 (15.88)
ø3/8 (9.52)
ø1/2 (12.70)
ø5/8 (15.88)
ø3/4 (19.05)
ø7/8 (22.22)
ø7/8 (22.22)
ø1-1/8 (28.58)
Closed pipe A Closed pipe B Closed pipe C Closed pipe insulation
Q'ty 3
2 (50)
ø1/4 (6.35)
Q'ty 4
2 (50)
ø3/8 (9.52)
Q'ty 4
2 (50)
ø1/2 (12.70)
Q'ty 9
ø1 (26)
3/8 (10)
z
Heat insulation
Heat insulation Application
Q'ty
3
for Liquid pipe
× 1
for Discharge
gas pipe × 1
for Suction gas
pipe × 1
Unit: in. (mm)
- (10 - 29) -
OPTIONAL PARTS OPTIONAL PARTS
