Dimensions
Liquid
pipe
1-5/8 (42)
1-9/16 (40)
(5 (127))
(3-3/8 (85))
3-7/16 (87)
19-9/16 (467)
P2-3/8 (60) x 5 = 11-13/16 (300)
3/8 (10)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
1-5/8 (42)
3/8 (10)
Dis-
charge
gas pipe
REDUCER
1-9/16 (40)
3-1/8 (80)
5 (127)
(6-1/16 (154))
8-9/16 (217)
25-1/16 (637)
2-3/8
(60)
3/8 (10)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
3-1/8
(80)
2-3/8
(60)
3-1/8
(80)
3-1/8
(80)
3-1/8 (80)
13/16 (20)
Suction
gas pipe
REDUCER
EXPANDER
3-1/8 (80)
13/16 (20)
9/16(15)
3-9/16 (90)
22-7/16 (570)
P3-1/8 (80) x 5 = 15-3/4 (400)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
1-9/16 (40)
2-13/16 (72)
3/8 (10)
9/16 (15)
5-1/8 (130)
Unit: in. (mm)
