Fujitsu Airstage J-II Series User Manual


DIMENSIONS
z
MODELS : UTD-GXSA-W, UTD-GXTA-W
4 x ø1/8 (3.2) Burring hole
2 x ø1/8 (3.2) Burring hole
2 x ø3/16 (5) Hole
2 x ø3/16 (5) Hole
25-3/8 (645)
10-3/8 (263)
26-7/8 (683)
1-1/8 (29)
3/8 (9)
1-5/8 (42)
ø7/8 (23)
3-5/16 (84)
2-15/16 (74)
7/8 (23)
9-13/16 (249) 8-1/2 (216)
21-7/8 (555)
P7-7/8 (200) x 3 = 23-5/16 (600)
The inside diameter
of the bush
2-15/16 (74)
4-9/16 (116)
5-1/8 (130)
1-3/8 (35)
3-1/16 (78)
5-13/16 (148)
7-1/16 (180)
1-1/8 (29)
z
MODELS : UTD-GXSB-W, UTD-GXSB-W
4 x ø1/8 (3.2) Burring hole
2 x ø3/16 (5) Hole
33-1/4 (845)
18-1/4 (463)
34-3/4 (883)
3-3/8 (86)
13-7/8 (353) 12-5/16 (312)
29-3/4 (755)
P7-7/8 (200) x 4 = 31-1/2 (800)
2-15/16 (74)
4-9/16 (116)
5-1/8 (130)
2 x ø1/8 (3.2) Burring hole
2 x ø3/16 (5) Hole
1-1/8 (29)
3/8 (9)
1-5/8 (42)
ø7/8 (23)
3-5/16 (84)
2-15/16 (74)
The inside diameter
of the bush
1-3/8 (35)
3-1/16 (78)
5-13/16 (148)
7-1/16 (180)
1-1/8 (29)
Unit : in. (mm)
- (10 - 81) -
OPTIONAL PARTS OPTIONAL PARTS
