Fujitsu CT114 User Manual

CT114_Rev2
9
General Information
Functions and Names of Sheet Keys
Key Name
Key Function
ON/OFF
Power
Turn
s the power on and off.
UP
key
Adjusts the brightness of the screen by pressing
the UP key
at
the [READY] screen.
Moves the cursor for selecting
an item in the menu.
Changes the value or letter of Mode Title.
DOWN
key
G
oes to the [Cleave Menu] screen by pressing DOWN key at the
[RESET] or [READY] screen.
Moves the cursor for selecting
an item in the menu.
Changes the value or the letter of Mode Title.
Fn
(Function)
key
By default,
[Basic settings] is linked to this key in the
Menu screen.
Pressing this key
will pause the cleaving procedure.
RESET
Reset key
Returns to the initial state from any other state.
After pressing this key, the
buzzer sounds and motors start the
reset
motion. During the reset motion,
“Reset …” is indicated. After the
reset
motion, [READY] or [RESET] screen is shown on
the monitor.
SET
Set key
Starts the
cleaving operation.
Wakes machine
from the sleep state.
ON/OFF key
y
DOWN key
RESET key
SET key
Fn key
UP key
The Fn key can be assigned to any of the shortcuts listed under “Function
Key” in “Basic Settings.”
