Getting started
Connecting the mouse
You can connect a USB mouse or a PS/2 mouse to your device.
Mouse,Connecting,
Connecting a USB mouse
► Connect the USB mouse to one of the USB ports on the device.
USBport,USBport
Connecting a PS/2 mouse
The PS/2 mouse is only detected by the device if you connect the mouse when
the device is switched off and then switch the device on again.
► Switch your device off.
If you do not attach a mouse to the PS/2 mouse port, you can disable the mouse
controller i n the BIOS Setup in order to free the IRQ12 for a different application.
► Connect the PS/2 mou
se to the PS/2 mouse port of the device.
PS/2mouse,Connecting,PS/2mouse,
► Switch your device on aga in.
Connecting the keyboard
You can con nect a USB keyboard or a PS/2 keyboard to y our device.
Keyboard,Connecting,
Connecting a USB keyboard
Use the supplied keyboard cable only.
USBport,Connecting,
► Plug the rectangular connector of the keyboard cable into the rectangular socket
on the underside or on the rear of the keyboard.
► Insert th e fla t rectangular USB plug of the keyboard cable into one of the d evice’s USB ports.
USBport
Connecting a PS/2 keyboard
Use the supplied keyboard cable only.
Connect
ingaPS/2keyboard
Connect
ing,
The PS/2 keyboard is only detected by the device if you connect the keyboard
when the device is switched off and then switch the device on again.
► Switch yo
ur d evice off.
► Plug the rectangular connector of the keyboard cable into the rectangular socket
on the underside or on the rear of the keyboard.
► Plug th
e round plug of the keyboard cable into the keyboard port on the device.
Keyboard,
► Switch your device on aga in.
Fujitsu 19
