Fujitsu Esprimo E5 Series - Reader

System expansions
Removing the module carrier with Sma rtCard reader
and/or WLAN module or multicar
dreader
► Disconnect any cables connected to the module carrier/multicard reader.
1
1
► Remove the screws (1) from the module carrier/m ulticard reader.
► Fold the drive ca
ge back into the closed position (see Chapter"
Closing the drive cage", Page 40).
1
► Slide t
he module carrier/multicard reader out of the casing in the direction of the arrow (1).
48 Fujitsu
