This chapter presents the individual hardware compon ents of your device. This w ill provide
you with an overview of the p orts and operating elements on the device. Please familiarise
yourself with these components before starting to work with your device.
Front
8
7
6
5
43
2
1
1 = Casing lock
(optional)
2 = US B ports (number of ports is
device-dependent)
3 = Micropho
ne port
4 = Headpho ne port
5 = ON/OFF swit
ch
6 = module bay for 3
1
/
2
inch drive
7=Insert/ej
ect button (CD/DVD)
8 = module bay for 5
1
/
4
inch drive
Rear
T
he power supply required for your device d epends on the configurat ion level chosen:
• Device with alternating voltage socket, monitor so cket and Primary Re sume Button.
• Device with alternating voltage socke t and main switch
• Device with alternating voltage socket and monitor socket
The configuration level of the device also determines whether it is fitted with high-profile
or low-profile boards, as shown in the diagrams below.
