System expan sio ns
Installing and removing low-profile boards (device-d epend ent)
Low-profilebo ard
For every slot there is a slot cover provided. If no board is installed, the slot cover protects the slot.
When you install a board, do not discard the corresponding slot cover.
For cooling, protection against fire and in order to comply with EM C regulations,
you must refit the slot cover if you remove the board.
Opening the board retaining mechanism
► Remove the casing cover (
see Chapter "
Removing th e casing cover", Page 37).
1
► Fold out the bo
ard retaining mechanism (1).
Fujitsu 59
