System expansions

Completing installation/removal of components

► Fasten the cover plate to the drive bay for the 3½ -inch drive (1).

► Fasten the blanking plate onto the drive bay in the casing cover.

► Fit the casing cover back onto the casing (see Chapter "

Reat taching the ca sing cover.", Page 38 ).

50 Fujitsu
