System expan sio ns
Installing/removing a SmartCard reader, WLAN
module or multicard reader (o
ptional, 3½ inch)
Operation of the module is not permitted in Taiwan.
It is possible to install
a SmartCard and/or WLAN module for wireless LAN (Local
Area Network) in the driv
e bay for the 3½ inch drive.
The SmartCard reader an
d WLAN module can be installed togethe r in the same
module carrier. The tw
o boards can also be installed individually without the
second board. The WLAN
module must be installed in the lower slot of the carrier
and the SmartCard read
er in the upper slot of the carrier.
If you want to inst al
l the SmartCard reader and the WLAN module
together, install
the WLAN module first.
To remove, carry ou
t the above steps in re verse order.
It is also possible to install a multicard reade r instead of the module carrier for
the S martCa rd reader and/or WLAN module.
Preparing to install/remove components
► Remove the casing cover (see Chapter "Removing the casing cover", Page 37) and
take the blanking plate off t he drive bay in the casing cover.
1
1
► Remove the cover plate from the drive bay for the 3½-inch drive (1).
Fujitsu 45
