System expansions
Reinstalling a slot cover
2
1
► Push the slot cover into the slot (1).
► Tighten the screw (2, optional).
Installing the bo
ard cag e
2
1
► Close t
he retaining mech anism on the board cage (1).
► Insert the board cage into the casing (1).
► Fit th
e casing cover back onto the casing (see Chapter "
Reat taching the ca sing cover.", Page 38 ).
If you
have installed or removed a board, please check the relevant PCI
slot
settings in the BIOS Setup. If necessary, change the settings. F urther
info
rmation is provided in the PCI bo ard documentation.
58 Fujitsu
