System expan sio ns

► Slide the ne w drive into the drive cage (1) un til it engages.

► Connect the cables to the drive. Make sure th e polarity is correct.

► Fit the casing cover back onto th e casing (see Chapter "

Reattaching the casing cover.", Page 38).

It may be necessary to mo dify the entry for the drive in the BIOS Setup .

Fujitsu 43
