System expansions
Reinstalling a slot cover
2
1
► Push the slot cover into the slot (1).
► Tighten the screw (2, optional).
Closing the board retaining mechanism
1
► Fold the board retaining mechanism to the closed position (1).
► Fit the casing cover back onto the casing (see Chapter "
Reat taching the ca sing cover.", Page 38 ).
If you have installed or removed a board, please check the releva nt PCI
slot settings in the BI OS Setup. If necessary, cha nge the settings. Further
information is provided in the PCI bo ard documentation.
62 Fujitsu
