Preliminary steps
No steps needed.
Installing a 3.5-inch HDD in a 3.5-inch installation frame
Figure 59: Installing the 3.5-inch HDD in the 3.5-inch installation frame (A)
▶
Lay the 3.5-inch HDD into the 3.5-inch installation frame as shown.
Figure 60: Installing the 3.5-inch HDD in the 3.5-inch installation frame (B)
Hard disk drive (HDD) / solid state drive (SSD)
RX1330 M4 Upgrade and Maintenance Manual 139
