Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

9.6.4 Replacing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: tool-less
CAUTION
▶
Dispose of used battery properly. Keep away from children.
▶
Do not throw flash backup units into the trash can. Batteries must
be disposed of in accordance with local regulations concerning
special waste.
Preliminary steps
▶
"Locating the defective server" on page 43.
▶
"Shutting down the server" on page
45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Removing the defective FBU
▶
Remove the FBU with the holder, see "Removing the FBU with the holder"
on page 228.
▶
Disconnect the FBU cable from the FBU, see "Disconnecting the FBU cable
from the FBU" on page 229.
▶
Remove the FBU from the holder, see "Removing the FBU from the holder"
on page 230.
Installing the new FBU
▶
Install the FBU in the FBU holder and connect the FBU cable to the FBU,
see "Preparing the FBU" on page 220.
▶
Install the FBU with the FBU holder, see "Installing the FBU" on page 223.
Expansion cards and backup units
RX1330 M4 Upgrade and Maintenance Manual 231

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
