Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
In the Tools
area click Tools: Chassis-IDProm Tool to download the file
(tool-chassis-Idprom-Tool.zip).
For Japan:
Follow the instructions provided separately.
Note on Advanced Thermal Design (A
TD)
If the Advanced Thermal Design (ATD) option is available and has been
enabled for your server, please set information within the Chassis ID
Prom T
ool accordingly.
The ATD option can only be ordered from the manufacturer as a factory
preset. To find out if your server is ATD-enabled, check for the ATD logo
on the identification rating plate.
For ATD logo and more information on Advanced Thermal Design
(ATD), see the operating manual of your server.
CAUTION
You can only set the ATD flag. Resetting the ATD flag using the Chassis
ID Prom Tool is not possible!
5.3.18
Configuring LAN teaming
Using ServerView Operations Manager
▶
Use the ServerV
iew Operations Manager to obtain more information on
existing LAN teams:
▶
In ServerView Operations Manager Single System View select System
Status from the Information/Operation menu.
▶
Under Network Interfaces select LAN Teaming.
▶
The Network Interfaces (Summary) overview shows all configured LAN
teams and their components. Choose a LAN team to display further
details:
LAN Team Properties: Properties of the selected LAN team
LAN Team Statistics: Available statistics about the selected LAN team
Basic software procedures
RX1330 M4 Upgrade and Maintenance Manual 93

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
