In the Ethernet Ports group, you will find detailed information on each
network controller in the managed PRIMERGY server
, including its MAC
address.
This information is only available with the iRMC S5 or above. Only
network controllers supporting the Command Line Protocol (CLP) will
be displayed.
For add-in cards the vendors provide documentation and tools,
offered on the Fujitsu support web pages:
https://ts.fujitsu.com/support/
Select the server
, select Downloads - More Details - Driver. Some
vendors bundle the documentation together with the driver package.
5.3.16.3 Looking for the WWN address of a fibre channel controller
There are several possible locations where these addresses can be found.
▶
Inform the customer about the new or changed WWN address.
Checking the label
▶
If available, check the label on the controller
. Beside the part number
, you
may find the WWN address.
Using an UEFI BIOS
▶
Enter the BIOS setup menu.
▶
Select the Advanced menu.
The addresses are displayed at the Advanced menu main page.
Only network controllers supporting the Command Line Protocol
(CLP) will be displayed.
5.3.16.4 Looking for the GUID address of an infiniband or Omni-Path
controller
There are several possible locations where these addresses can be found.
▶
Inform the customer about the new or changed GUID address.
Basic software procedures
90 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
