Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Figure 97: Numbering of the dual fan modules
1 Fan 1
2
Fan 2
3
Fan 3
4 Fan 4
5 Fan 4
8.3 Replacing fan modules
Field Replaceable Unit
(FRU)
Hardware: 10 minutes
Tools: tool-less
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Shutting down the server" on page 45.
Fans
RX1330 M4 Upgrade and Maintenance Manual 179

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
