Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

4.6 Connecting the power cord
CAUTION
The server automatically adjusts to a mains voltage in the range from
100 V - 240 V
.
▶
You may only operate the server if its rated voltage range
corresponds to the local mains voltage.
Standard power supply
▶
If applicable, connect the mains plug to a grounded mains outlet in the
inhouse power supply network.
▶
Connect the power cord to the PSU.


Figure 10: Locking the cable tie of a standard PSU
▶
Thread the cable tie through the eye (1).
▶
Pull the cable tie tight to secure the power cord (2).
The insulated connector cannot be disconnected from the server
accidentally
.
Y
ou can loosen the cable tie by opening the small locking lever (2).
Basic hardware procedures
56 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
