For the cable plan, see "Appendix B" on page 365.
Concluding steps
▶
Install the corresponding riser module, see "Installing a riser module" on
page 61
.
▶
"Reassembling" on page 52.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
▶
"Updating expansion card firmware" on page 72.
▶
"Enabling Option ROM scan" on page 73.
▶
"Resuming BitLocker functionality" on page 86.
9.5.2 Removing an expansion card
Upgrade and Repair Unit
(URU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
"Suspending BitLocker functionality" on page 65
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 59.
Removing the expansion card
▶
If applicable, disconnect internal cables from the expansion card.
Expansion cards and backup units
RX1330 M4 Upgrade and Maintenance Manual 203
