Insert the HDD/SSD module into a drive bay and carefully push back as far
as it will go (1).
▶
Close the locking lever to lock the HDD/SSD module in place (2).
▶
When using a RAID array, add the additional HDD/SSD to the RAID array
.
Configuring the RAID array, see the documentation of the RAID
controller, used in your configuration, see "Documentation overview" on
page 26.
Concluding steps
No steps needed.
7.5.3 Removing 2.5-inch HDD/SSD modules
Customer Replaceable
Unit (CRU)
Hardware: 5 minutes
Tools: tool-less
Preliminary steps
▶
If the HDD/SSD module to be removed is combined into a RAID array,
please proceed as follows:
Hard disk drive (HDD) / solid state drive (SSD)
RX1330 M4 Upgrade and Maintenance Manual 155
