Figure 134: Position of the shoulder screw caps
1 FBU 1 2 FBU 2
9.6.2 Installing an FBU
Upgrade and Repair Unit
(URU)
Hardware: 15 minutes
Tools: Phillips PH1 / (+) No.1 screw driver (for installing the TFM)
Preliminary steps
▶
"Shutting down the server" on page 45
.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
Expansion cards and backup units
RX1330 M4 Upgrade and Maintenance Manual 219
