For more information, see the "ServerView Operations Manager - Server
Management" user guide.
Using Infrastructure Manager
When using Infrastructure Manager and replacing LAN controller or system
board, you have to deapply the profile before replacing and apply the profile
again after replacing.
Please refer to the following manuals of the Infrastructure Manager.
See manual "FUJITSU Software Infrastructure Manager
V2.6.0 User's
Guide", section "2.4.2 Profiles and Policies", available at:
https://ts.fujitsu.com/support/
For Japan:
See manual "FUJITSU Software Infrastructure Manager
V2.6.0 解説書",
section "2.4.2 プロファイルとポリシー", available at:
https://www.fujitsu.com/jp/products/software/infrastructure-software/
infrastructure-software/serverviewism/technical/
After replacing or upgrading LAN controllers
▶
You need to restore the configuration for the LAN T
eaming, using the LAN
driver utility or OS teaming software.
Ensure that the controllers have been assigned as primary or secondary
according to your requirements.
For more information, see the relevant LAN driver manual.
After replacing a system board
The following procedure must be done for each system board that is
replaced.
▶
Confirm with the customer whether the onboard LAN controller you have
replaced has been used as part of a LAN teaming configuration.
▶
If LAN teaming has been active, you will need to restore the configuration
using the LAN driver utility or OS teaming software.
Basic software procedures
94 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
