Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
If applicable, disconnect external cables to the expansion card.
▶
"Getting access to the component" on page
48
.
▶
"Locating the defective component" on page 44.
▶
Remove the corresponding riser module, see "Removing a riser module" on
page 59.
Removing the defective expansion card
▶
Remove the expansion card, see "Removing an expansion card" on
page 203.
▶
If the slot bracket on the defective expansion card is to be reused, remove it
from the expansion card, see "Removing slot brackets" on page 187.
Installing the new expansion card
▶
If applicable, install the slot bracket, see "Installing a slot bracket" on
page 186.
▶
Install the expansion card, see "Installing an expansion card" on page 196.
Connecting cables to the expansion card
▶
If applicable, connect internal cables to the expansion card.
For the cable plans, see "Appendix B" on page 365
.
Concluding steps
▶
Install the corresponding riser module, see "Installing a riser module" on
page 61
.
▶
"Reassembling" on page 52.
▶
If applicable, connect external cables to the expansion card.
▶
"Connecting the power cord" on page 56.
▶
"Switching on the server" on page 58.
▶
"Enabling replaced components in the BIOS" on page 81.
Expansion cards and backup units
206 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
