Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

Removing and installing Field Replaceable Units involves complex
maintenance procedures on integral server components. Procedures will
require shutting down, opening and disassembling the server.
CAUTION
Maintenance procedures involving Field Replaceable Units must be
performed exclusively by Fujitsu service personnel or technicians
trained by Fujitsu. Please note that unauthorized interference with the
system will void the warranty and exempt the manufacturer from all
liability.
Components that are handled as Field Replaceable Units
–
CPU (replacement)
–
SAS/SAT
A HDD backplane
–
SAS expander board
–
PCIe riser card
–
Front panel module
–
Front panel cable
–
System board
–
Trusted Platform Module (TPM)
–
Power distribution board (PDB)
–
Liquid cooling (LC)
–
Non hot-plug PSUs
–
Non hot-plug fan modules
–
Fan cable
–
Mid Plane kit
–
Memory modules (special RX4770 M5 and memory slots from A to M on
bottom system board)
–
M.2 SSDs (special RX4770 M5 and M.2 SSDs with 110 mm length)
Please ask your local Fujitsu service center for more information.
Before you start
24 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
