Note on BIOS settings recovery
When replacing the CMOS battery, the BIOS settings will be reset.
Ensure to note down your current BIOS settings including "System
Time" and "System date" before replacing the CMOS battery
.
Preliminary steps
▶
"Locating the defective server" on page 43
.
▶
"Shutting down the server" on page 45.
▶
"Disconnecting the power cord" on page 46.
▶
"Getting access to the component" on page 48.
▶
"Removing the air duct" on page 63.
Replacing the defective CMOS battery
Figure 202: Replacing the CMOS battery
System board and components
RX1330 M4 Upgrade and Maintenance Manual 293
