Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

LAN speed indicator (2)
Status Description
yellow on Data traffic at a transfer rate of 1 Gbit/s.
green on Data traffic at a transfer rate of 100 Mbit/s.
off Data traffic at a transfer rate of 10 Mbit/s.
Indication of LAN connection supporting Energy Efficient Ethernet (EEE
mode)
To configure the EEE mode, it is necessary that the onboard LAN or an add-in
LAN card supports this mode and the connected switch supports this mode as
well.
Indicator if
EEE mode is
active
Status Description
LAN link/
transfer
indicator
short flashing green 3x,
then off
A LAN connection has been
established (1 Gbit or 100
Mbit)
and EEE mode is active.
LAN speed
indicator
short flashing yellow 1x,
then 2 seconds off
green off
Data traffic at a transfer rate of
1 Gbit/s.
short flashing green 1x,
then 2 seconds off
yellow off
Data traffic at a transfer rate of
100 Mbit/s
Note on the onboard LAN controller
The system board is equipped with a Gigabit Ethernet Controller that
supports transfer rates of 10 Mbit/s, 100 Mbit/s and 1 Gbit/s.
The separate management LAN connector is used as a management
interface (iRMC S5) and is prepared for operation with the Remote
Management. Optionally LAN connector 1 can also be used for iRMC
S5 server management.
Appendix A
356 Upgrade and Maintenance Manual RX1330 M4

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
