16.2.3.5 Indicator on FJBU
Figure 248: Indicator on FJBU
1 FJBU status indicator
FJBU status indicator (1)
Status Description
flashing green The battery unit is charging.
flashing green
slowly
The battery unit is discharging.
green on The battery unit is fully charged.
flashing orange A battery unit failure has been detected.
Possible causes:
– Capacity failure
– Overheating
orange on
A general battery failure has occurred.
Appendix A
358 Upgrade and Maintenance Manual RX1330 M4
