Fujitsu PRIMERGY RX1330 M4 Upgrade And Maintenance Manual

▶
Select the memory module which shows the pre-failure status.
▶
Click on Reset Status.
The Reset Status button will only be available if the selected memory
module contains errors.
▶
Ensure that all pre-fail/fail status issues have been resolved in ServerView
Operations Manager
.
Using the command line interface (Linux/VMware only)
The memory error counter can be reset using the meclear utility which is part
of the ServerView agents for Linux.
meclear (Memory Module Error Counter Reset Utility) allows to reset
the error count collected for a memory module, for example after it has
been replaced.
For more Information, see the meclear manual pages.
▶
Log in as root.
▶
Enter the command below
, followed by
[ENTER]:
/usr/sbin/meclear
▶
Select the number of a memory module with a status other than OK or Not
available.
▶
Repeat the step above until all memory modules show the OK status.
▶
Ensure that all pre-fail/fail status issues have been resolved in ServerView
Operations Manager.
Using Infrastructure Manager
The status of server (node) which failed memory module is installed becomes
error.
When replacing the memory module, the status will be updated after getting
information manually or automatically updated daily.
Proceed as follows to get node information with Infrastructure Manager:
▶
Start up the GUI of the Infrastructure Manager and login.
Basic software procedures
RX1330 M4 Upgrade and Maintenance Manual 77

Fujitsu PRIMERGY RX1330 M4 Specifications

General

Chipset	Intel C246
Processor	Intel Pentium, Intel Celeron
Memory Type	DDR4
Memory	Up to 64 GB
Memory Slots	4 DIMM slots
Drive Bays	4 x 3.5-inch or 8 x 2.5-inch
Network	2x 1GbE onboard, optional additional NICs
Power Supply	450W
Form Factor	1U
RAID Controller	optional SAS RAID controller
