TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
389
11.6 Applying thermal paste
I
– For the Japanese market, the service engineer must follow the
instruction provided separately.
– If the CPU upgrade or replacement kit contains a new CPU heat sink,
a thin layer of thermal compound has already been pre-applied to its
lower surface. In this case, please proceed with section "Installing
heat sinks" on page 385.
Figure 282: Thermal paste syringe TC-5026
One thermal compound syringe (A3C40142460 / 34035576) contains thermal
paste for three CPUs.
Field Replaceable Unit
(FRU)
Hardware: 5 minutes
Tools:
tool-less
