TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
87
Basic hardware procedures
4.6 Connecting the power cord
V CAUTION!
The server supports a mains voltage in the range of 100 V to 240 V. You
may only operate the server if its rated voltage range corresponds to the
local mains voltage.
Ê
Connect the power cords to the PSUs.
Ê
Connect the mains plugs to grounded mains outlets in the in-house power
supply network or power outlets of the rack socket strip.
I
It will take about 60 seconds until the server can be powered on.
Securing power cords
If the PSU cable bracket has not yet been mounted to the PSU, proceed as
follows:
Figure 37: Preparing the PSU cable bracket
Ê
Press down on the locking lever on the PSU cable bracket (1) and pull the
loop away from the PSU cable bracket anchorage as far as it will go (2).
