TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual
405
12.5 Slimline ODD and LSD in Multibay box
12.5.1 Installing the slimline ODD or LSD
12.5.1.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê
"Disconnecting the power cord" on page 59
Ê
"Getting access to the component" on page 61
I
The front cover only needs to be removed in order to remove
accessible drive dummy covers. If the Multibay box is already
installed in the server and will be removed in order to install a slimline
ODD or LSD module, skip this step.
Ê
"Removing the system air duct" on page 91
Ê
"Removing the system fan holder" on page 93
Ê
"Removing a riser module" on page 98 (if applicable)
Ê
"Removing the Multibay box" on page 411 (if applicable)
12.5.1.2 Installing the slimline ODD into the Multibay box
Ê
Press up on the locking tab to disengage the slimline ODD dummy module
(see figure 305).
Ê
From inside the Multibay module, press out on the ODD dummy module and
pull it out of its bay.
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
– Phillips PH2 / (+) No. 2 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
