TX2560 M2 / RX2560 M2 Upgrade and Maintenance Manual 427
Accessible drives
12.7 Ultraslim ODD in ultraslim ODD adapter
12.7.1 Installing the ultraslim ODD
12.7.1.1 Preliminary steps
Ê
"Shutting down the server" on page 58
Ê "Disconnecting the power cord" on page 59
Ê "Getting access to the component" on page 61
I The front cover only needs to be removed in order to remove
accessible drive dummy covers.
Ê "Removing the system air duct" on page 91
Ê "Removing the system fan holder" on page 93
Ê "Removing a riser module" on page 98 (if applicable)
Upgrade and Repair Unit
(URU)
Hardware: 10 minutes
Tools:
– Phillips PH0 / (+) No. 0 screw driver
– Slotted screw driver (for bending in or out accessible drive
mounting brackets)
