460
Upgrade and Maintenance Manual TX2560 M2 / RX2560 M2
System board and components
V CAUTION!
UFM contains customer information (e.g. IP address, License etc.). After
replacing the UFM, you must pass the defective UFM to the customer,
and ask for disposal. If the disposal of the defective UFM is requested by
the customer, you break it according to the following procedure, and
dispose it.
Figure 343: Tools for breaking the UFM
Figure 344: UFM breaking method
Ê
Use a flat nose pliers and a combination pliers to break the UFM in
half as shown in the figure.
