Replacing the Roller Set
454
4. Install a new pick roller on the ScanSnap.
Insert the left end of the shaft into the slot, and lower the other end gradually.
5. Rotate the bushing to lock the shaft.
6. Close the sheet guide.
Make sure that both ends of the sheet guide are locked firmly.
ATTENTION
Confirm that the pick roller is installed properly. Otherwise, paper jams or other feeding errors
may occur.
To Next Page
