6. After finishing the settings for one channel, click the Set button.
Note: Be sure to do this before moving another channel.
7. Repeat steps 2-6 to set up each channel.
When running Config Management for Tab Settings:
1. From the Maintenance menu, click VDR Config Management and then Config.
2. Click the Upload button to record data to the VDR memory.
3. Click the Write button to save data to the DRU, backup HDD and CF.
The buttons in the Setting Area are as follows:
Set: Save edited data.
Capture: Received data shown in the serial window dialog box
Select Equipment: Select equipment settings (saved to the database) to reflect in
a channel.
Reflect Equipment: Save the equipment setting data to the database.
Check: Check all channels. OK or NG (No Good) shown in
Information window.
Individual Item Explanation:
Active*: Put check in check box to make channel active.
Brand: Enter brand name.
Type No. (Equipment Name)*: Set type no. (equipment name)
Check*: Do equipment check.
Data Name*: Enter data name.
Data Type: Enter data type.
Baud Rate: Set baud rate (Available for SI01 to SI08).
Data Bit: Set number of bits (Available for SI01 to SI08).
Parity Bit: Set parity bit (Available for SI01 to SI08).
Stop Bit: Set stop bit (Available for SI01 to SI08).
Source Checksum: Enter checksum for GPS source.
Time out: Set time out.
Equipment Category*: Set equipment category.
Board Name*: Enter board names where channels are present.
Note*: Enter note.
* Marked Items: For easy identification of input source, enter Equipment Category, Brand,
Type No., Date and Name.
