5.2 Creation
The Creation feature initializes recording media.
Note1: This feature deletes ALL configuration data. Backup all VDR configuration data.
Note2: When you initialize medium that is a different format for the DRU or Backup HDD,
delete all partitions with the disk management tool of Windows.
Note3: When the Creation is failed, try again. If you can not initialize recording media, try
under condition as shown below:
・ Do the Creation by the direct connection. (When the Creation by the LAN
connection is failed.)
・ Delete all partitions of the DRU or Backup HDD with the disk management tool of
Windows to do the Creation.
If the Creation is still failed, request service to repair/replace the DRU or Backup
HDD.
Initialize the DRU as follows (LAN connection):
1. Set the Playback/CPU switch in the DCU to the CPU position.
2. Check that an Ethernet cross cable is connected between J14 in the DCU and the PC.
3. Open the Tool menu.
4. Select Media Management to open the VDR Media Management window.
5. Check that IP address shown in the LAN Connect to IP in VDR Media Table Area is
the same as the IP address access point.
6. Check “LAN Connect to IP” in the VDR Media Table column.
7. Click the Analyze button. A list of recording media connected to the VDR appears.
8. Put a checkmark in the box of the Select column for the DRU in the Name column.
Select “DRU Creation” from the Operation dropdown list in the Operation area.
9. Click the Run button.
Initialize the Backup HDD as follows (LAN connection):
1. To format the Backup HDD, place a checkmark in the Select column of the listed
record media in the Name column of the VDR Media Management dialogue box.
2. From the Operation drop down list of the Operation area, select “Backup HDD
Creation (Radar) or “Backup HDD Creation”.
Two partition tools are available for the Backup HDD in the Media Management as
below.
Backup HDD creation：
This tool is used when the number of the SXGA video signal connected to the Backup
HDD is the same as the DRU. The same partition is created on both DRU and HDD.
(1) When two SXGA video signals are recorded onto the HDD while 9-GB DRU is
connected.
(2) When an SXGA video signal is recorded onto the HDD while 6-GB DRU is
connected.
Backup HDD creation (radar)：
This tool is used when two SXGA video signals are recorded onto the HDD with 6-GB
DRU connected. The HDD has an area (radar) to record the second radar signal in
addition to the same partition as the DRU. This tool cannot be used when 9-GB DRU
is connected.
3. Press the Run Button.
