FUTABA T6K-V2 - Aileron Differential (AIL DIF)

148
Glider
Function
Method
①Callthemenuscreenfromthe
homescreenbypressingthe+
keyfor1second.
＋
② Select
fromthemenuwiththe
Jogkey.
③Openthesettingscreenby
pressingtheJogkey.
（1second）
Callingthesettingscreen
1AIL 2AIL1AIL1FLP 2AIL1FLP 2AIL2FLPWINGTYPE
Two servos can be used for ailerons and a differen-
tial can be applied to left and right aileron operation.
The left and right aileron differential can be adjusted
independently. This function is restricted to 2 servo
aileron.
Connect the left aileron to CH1 (AIL) and the right
aileron to CH6.
ŏ7KHXSDQGGRZQDQJOHRIWKHOHIWDQGULJKWDLOHURQ
FRQWUROVXUIDFHFDQEHDGMXVWHGLQGLYLGXDOO\
"AILDIF"
AILDIF
Ailerondifferential
(GLIDER)
Aileron1（CH1）rate
Aileron6（CH6）rate
（Aileronrate）
L：AileronStickLeftsiderate
R：AileronStickRightsiderate
● Selectthesettingitemwith
theJogkey.
Aileron1
(CH1)
Aileron6
(CH6)
SelecttheLeft/Rightwiththeai-
leronstick.
■Activatingthefunction
①Selectthe"2AIL"or"2AIL1FLP"
"2AIL2FLP"byWINGtype(MDL
TYP).
■ Aileronrate
＋ −
or
②Selectthe"AIL1"itemandmovetheai-
leronsticktotheleftandrightandad-
justthetravelofeachservobypressing
the+keyor‒key.
Range：-120to+120%
Default：+100%
● Whenyouwanttoreturntotheinitialvalue,pressthe+key
and‒keysimultaneously.However,whenthepolarityis
changedonlythenumberreturnstotheinitialvalue.
（Adjustthe"AIL6"iteminthesamewayas② .）
AileronDifferential
