161 232003110G (03)
NOTE
It is important that the 1/4" air tubing has clean, straight cuts on each end. Jagged or
slanted cuts will not produce adequate sealing capabilities.
4) Please fine the Air Assist Valve which is located in the right side of machine.
5) Plug the air compressor’s power cord A into the AC internal power socket.
6) Plug the female end of power cord B to the AC internal power socket and the male end to
an external power outlet.
Power Cord B Socket
Power Cord A Socket
AC Internal
Power Sockets
To Next Page
