1 PRODUCT DESCRIPTION 1.3 CUSTOM PROGRAMMABILITY
1
1.3 CUSTOM PROGRAMMABILITY 1.3.1 INTRODUCTION
The ALPS offers a high degree of custom programmability. Custom programming of the ALPS is accomplished using
Xpression Builder. Xpression Builder is a Windows based program that allows the user to design programmable logic and
make I/O (Input/Output) assignments for the ALPS and other GE Power Management relays. Xpression Builder is included
with ALPS software suite on the GE Power Management CD. A complete description of Xpression Builder is included in
Chapter 13: XPRESSION BUILDER.
1.3.2 PROGRAMMABLE LOGIC
In addition to the pre-programmed line protection schemes and configurable I/O, the ALPS relay includes the capability for
the user to design custom logic. This logic may be used to supplement or to replace the built-in scheme logic. The program-
mable logic includes the following: up to 40 logic gates (AND, OR, NOT), each with up to 4 inputs; 8 programmable timers
each with a settable pickup and dropout delay; 8 counters; and 8 latches.
1.3.3 CONFIGURABLE INPUTS
All of the contact converters (Digital Inputs) in the ALPS are user configurable. However, each ALPS relay is shipped with
Default Contact Converter Assignments as shown below and on the default elementary diagrams on pages 1–49 to 1–52.
Each configurable input can be assigned only one flag – assigning more than one flag to a configurable
input may cause maloperation!
Table 1–3: ALPS DEFAULT CONTACT CONVERTER ASSIGNMENTS: SINGLE PHASE MODEL
INPUT DESCRIPTION MNEMONIC INDEX # NOTE
CC1 RECEIVER #1 RCVR1 12
CC2 RECEIVER #2 RCVR2 13 (if used)
CC3 EXTERNAL STOP CARRIER STCR 10 (Blocking Scheme Only)
CC4 BLOCK PILOT TRIPPING BLPTRP 11 (Blocking Scheme Only)
CC5 ENABLE THREE PHASE TRIPPING ETRP3P 7
CC6 REMOTE TARGET RESET RESET 20
CC7 BKR 1 52b PHASE A 52B_1A 1
CC8 BKR 1 52b PHASE B 52B_1B 2
CC9 BKR 1 52b PHASE C 52B_1C 3
CC10 BKR 2 52b PHASE A 52B_2A 4
CC11 BKR 2 52b PHASE B 52B_2B 5
CC12 BKR 2 52b PHASE C 52B_2C 6
Table 1–4: ALPS DEFAULT CONTACT CONVERTER ASSIGNMENTS: THREE PHASE MODEL
INPUT DESCRIPTION MNEMONIC INDEX # NOTE
CC1 RECEIVER #1 RCVR1 12
CC2 RECEIVER #2 RCVR2 13 (if used)
CC3 EXTERNAL STOP CARRIER STCR 10 (Blocking Scheme Only)
CC4 BLOCK PILOT TRIPPING BLPTRP 11 (Blocking Scheme Only)
CC5
CC6
CC7 BKR 1 52B 52B_1 1
CC8 BKR 2 52B 52B_2 4
WARNING
