2.5 REFERENCE TABLES 2.5.1 INDEX NUMBERS
Table 2–9: INDEX NUMBERS – CONTACT CONVERTER INPUT ASSIGNMENT
ALPS with Single Phase Tripping ALPS with Three Phase Tripping
Index Description Mnemonic Index Description Mnemonic
1 Breaker #1 52b Contact Input Phase A 52B_1A 1 Breaker #1 52b Contact Input 52B_1
2 Breaker #1 52b Contact Input Phase B 52B_1B 2 Spare
3 Breaker #1 52b Contact Input Phase C 52B_1C 3 Spare
4 Breaker #2 52b Contact Input Phase A 52B_2A 4 Breaker #2 52b Contact Input 52B_2
5 Breaker #2 52b Contact Input Phase B 52B_2B 5 Spare
6 Breaker #2 52b Contact Input Phase C 52B_2C 6 Spare
7 Enable Three Phase Trippin
g
EXTRP3P 7 Spare
8 Chan
g
e Settin
g
Group Input (BIT0) CGST1 8 Chan
g
e Settin
g
Group Input (BIT0) CGST1
9 Chan
g
e Settin
g
Group Input (BIT1) CGST2 9 Chan
g
e Settin
g
Group Input (BIT1) CGST2
10 External Contact Input to Stop Carrier * STCR 10 External Contact Input to Stop Carrier * STCR
11 External Contact Input to Block Pilot
Trippin
g
*
BPLTRP 11 External Contact Input to Block Pilot
Trippin
g
*
BLPTRP
12 Receiver 1 Input RCVR1 12 Receiver 1 Input RCVR1
13 Receiver 2 Input RCVR2 13 Receiver 2 Input RCVR2
14 External Reclose Initiate 1 Pole EXRI1P 14 Spare
15 External Reclose Initiate 3 Pole EXRI3P 15 External Reclose Initiate 3 Pole EXRI3P
16 External Reclose Inhibit EXRINH 16 External Reclose Inhibit EXRINH
17 External Reclose Cancel EXRCNL 17 External Reclose Cancel EXRCNL
18 Reclose Reset RCLRST 18 Reclose Reset RCLRST
19 External Phase 3 Reclose CLOS3P 19 Spare
20 External Contact Input to Reset ALPS
Trip Tar
g
et Display
RESET 20 Spare
21 Spare 21 Spare
22 External Contact Input to Disable
Outputs
DISOUT 22 External Contact Input to Disable
Outputs
DISOUT
23 External Contact Input to Tri
gg
er
Oscillo
g
raphy Capture
OSCTRG 23 External Contact Input to Tri
gg
er
Oscillo
g
raphy Capture
OSCTRG
24 Manual Lockout MANLKT 24 Manual Lockout MANLLT
25 CONFIGURABLE INPUT1 CNFDI1 25 CONFIGURABLE INPUT1 CNFDI1
26 CONFIGURABLE INPUT2 CNFDI2 26 CONFIGURABLE INPUT2 CNFDI2
27 CONFIGURABLE INPUT3 CNFDI3 27 CONFIGURABLE INPUT3 CNFDI3
28 CONFIGURABLE INPUT4 CNFDI4 28 CONFIGURABLE INPUT4 CNFDI4
29 CONFIGURABLE INPUT5 CNFDI5 29 CONFIGURABLE INPUT5 CNFDI5
30 CONFIGURABLE INPUT6 CNFDI6 30 CONFIGURABLE INPUT6 CNFDI6
31 CONFIGURABLE INPUT7 CNFDI7 31 CONFIGURABLE INPUT7 CNFDI7
32 CONFIGURABLE INPUT8 CNFDI8 32 CONFIGURABLE INPUT8 CNFDI8
NOTE
: Any of the above si
g
nals (1 to 32) may be assi
g
ned to the 8 available ALPS Contact Converter Inputs (CC1 to CC8). Those 8
si
g
nals will also be available for use for the Pro
g
rammable Outputs and/or the Confi
g
urable Lo
g
ic. Unassi
g
ned si
g
nals will
NOT be available.
NOTE:
Contacts are normally open; add 1000 to number to close contact under normal conditions.
* Applies to Blockin
g
Scheme Only
