GE ALPS - M4 Phase Units - Zone 4

GE Power Management
ALPS Advanced Line Protection System 10-5
10 ALPS TEST PROGRAM 10.2 TEST CALCULATIONS
10
10.2.8 M4 PHASE UNITS – ZONE 4
The following dialog box is displayed for this test. The values are the default values used when the user selects New Test
File from the File menu.
Figure 10–8: M4 PHASE UNITS – ZONE 4 DIALOG BOX
10.2.9 MOB PHASE UNIT
The following dialog box is displayed for this test. The values are the default values used when the user selects New Test
File from the File menu.
Figure 10–9: MOB PHASE UNIT DIALOG BOX
