C.3 POINT LISTS APPENDIX C
C
C.3 POINT LISTS C.3.1 DESCRIPTION
The following tables give a list of data points defined for each object in the relay.
C.3.2 BINARY INPUT, BINARY INPUT CHANGE
Table C–3: POINT LIST: OBJECTS 01 & 02 (Sheet 1 of 5)
BINARY INPUT (OBJECT 01)
BINARY INPUT CHANGE (OBJECT 02)
INDEX DESCRIPTION EVENT CLASS
ASSIGNED TO
REMARKS
0 Relay In Service Class 1
1 Critical Failure Class 1
2 Non-Critical Failure Class 1
3 Warm Restart Class 1
4 Settings Group 1 Active Class 1
5 Settings Group 2 Active Class 1
6 Settings Group 3 Active Class 1
7 Settings Group 4 Active Class 1
8 Recloser Disabled Class 1
9 Recloser in Reset Class 1
10 Recloser in Progress Class 1
11 Recloser in Lockout Class 1
12 Breaker #1 / Breaker #1 Phase A is Open Class 1
13 Breaker #1 Phase B is Open Class 1
14 Breaker #1 Phase C is Open Class 1
15 Breaker #1 / Breaker #1 Phase A is Closed Class 1
16 Breaker #1 Phase B is Closed Class 1
17 Breaker #1 Phase C is Closed Class 1
18 Breaker #2 / Breaker #2 Phase A is Open Class 1
19 Breaker #2 Phase B is Open Class 1
20 Breaker #2 Phase C is Open Class 1
21 Breaker #2 / Breaker #2 Phase A is Closed Class 1
22 Breaker #2 Phase B is Closed Class 1
23 Breaker #2 Phase C is Closed Class 1
24 DO – Phase A Trip Bus Class 1
25 DO – Phase B Trip Bus Class 1
26 DO – Phase C Trip Bus Class 1
27 DO – Single Pole Reclose Initiate Class 1
28 DO – Three Pole Reclose Initiate Class 1
29 DO – Reclose Cancel Class 1
30 DO – Key Transmitter 1/Carrier Start Class 1
31 DO – Key Transmitter 2/Carrier Stop Class 1
32 DO – Three Phase Trip Enable Class 1
33 …Reserved…
34 …Reserved…
35 DO – Reclose In Progress Class 1
36 DO – Line Overload Alarm Class 1
37 DO – Recloser in Lockout Alarm Class 1
38 DO – Trip Circuit Alarm Class 1
