13.2 XPRESSION BUILDER FLAGS 13 XPRESSION BUILDER
13
13.2 XPRESSION BUILDER FLAGS 13.2.1 CONTACT CONVERTER INPUTS
13.2.2 INPUT/OUTPUT FLAGS
The input flags available for assignment to user defined logic are as follows:
Table 13–2: CONTACT CONVERTER INPUT FLAGS
INDEX DESCRIPTION MNEMONIC
0 No Assignment to Input NONE
1 Breaker #1 52b Contact Input 52B_1
4 Breaker #2 52b Contact Input 52B_2
8 Change Setting Group Input Bit 0 CGST1
9 Change Setting Group Input Bit 1 CGST2
10 External Contact Input to Stop Carrier STCR
11 External Contact Input to Block Pilot Tripping BPLTRP
12 Receiver 1 Input RCVR1
13 Receiver 2 Input RCVR2
15 External Reclose Initiate 3-Pole EXRI3P
16 External Reclose Inhibit EXRINH
17 External Reclose Cancel EXRCNL
18 Reclose Reset RCLRST
19 External Manual Close EMNCLS
22 External Contact Input to Disable Outputs DISOUT
23 External Contact to Trigger Oscillography OSCTRG
24 Manual Lock-Out MANLKT
25 Configurable Input 1 CNFDI1
26 Configurable Input 2 CNFDI2
27 Configurable Input 3 CNFDI3
28 Configurable Input 4 CNFDI4
29 Configurable Input 5 CNFDI5
30 Configurable Input 6 CNFDI6
31 Configurable Input 7 CNFDI7
32 Configurable Input 8 CNFDI8
Table 13–3: CONFIGURABLE INPUTS
INDEX DESCRIPTION MNEMONIC
25 Configurable Input 1 CNFDI1
26 Configurable Input 2 CNFDI2
27 Configurable Input 3 CNFDI3
28 Configurable Input 4 CNFDI4
29 Configurable Input 5 CNFDI5
30 Configurable Input 6 CNFDI6
31 Configurable Input 7 CNFDI7
32 Configurable Input 8 CNFDI8
